gweike cloud RF Metal Tube Laser Cutter & Engraver with Rotary
- 5MP camera,preview design and visually position it on the material.
- Silent fan and water pump, decibel≤70dB.
- Live Preview & Image Extraction.
- 100% pre-installed 1-step fast assembly.
- WIFI/USB/Internet cable connection.
- Lightburn/Gweikecloud online/Gweike offline control.
- All modules and major components are made of high-strength metal.
What Can We Offer Our Customers
Live Camera Preview & Image Extraction
Adopt 5mp wide-angle camera to precisely locate the position of the design on the material, and monitor the working condition of the machine in real timeintelligently extract the pattern from the surface of any object and cut or engrave out the recognized pattern.
Intelligent material recognition and automatic parameter setting
The cloud-based online operating system, by recognizing the QR code on the material, can directly obtain the thickness and type of the processed material, thus automatically setting up the best focal length, speed, power, times of cuts and other parameters for cutting or engraving that match the current material.
RF Metal Laser Tube
A more expensive laser source that uses radio frequency to fire a fast pulsing laser with extremely quick repeatability. They engrave with ultra-fine detail, due to a smaller laser spot size. They have a longer lifespan of up to approximately 10-12 years of moderate use before the gas depletes and need to be refurbished or replaced.
The standard Rotary Attachment is ideal for engraving cylinder items with your laser. From glasses, to mugs, to wine bottles, to flashlights.
Support gweike cloud online, Gweikecloud offline and lightburn three controllers.Support WIFI-network cable and USB three connection methods.
Smoke Air Filter
Environmental protection without pollution. Three-stage filtration.The first is bag filtration of large particles.The second is HEPA filtration of particles larger than 0.03um.The third is activated carbon adsorbs of smoke and dust odour.
The Quieter the Better
During normal printing, gweike cloud has an average noise level of about 70 dB(A). Equipped with a much quieter fan the speed can be adjusted automatically according to the real-time temperature, realizing a noise level decrease of about 16 dB(A), so that you can truly focus on your making.
What Other Advantages?
Live Preview & Image Extraction
Allowing precise locating and monitoring to save much time and guarantee higher accuracy.
It can engrave on Sphere, tilt plane, curved surface and different height object. It can create 3D image on diamond,woods, and acrylics ,etc.
Cloud online Operation
Your Gweikecloud runs from a web browser, which means there’s no software to install - ever. Drag and drop your designs right onto your material. Upgrades are instant and seamless
Online Design Catalog
If you do n’t have professional drawing design experience or you do n’t have time to design drawings, Gweikecloud provides massive materials for free download or you can purchase online
Two Y-axis Simultaneous Motion Design
The Y-axis on both sides have been equipped two rails guide to ensure run more smoothly and higher cutting performance.
Three-axis Adopts Linear Guide
Adopted Taiwan Hiwin 3 axis linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.
Safe For Children
Adopt fully enclosed structural design to give users the best protection.Products are CE-certified, FCC-certified, FDA-certified, all electronic components comply with 3C standards.
Convenient- You can remotely control computers and machines, adjust parameters and solve problems.
Laser Power 38W
Laser TypeRF Metal Laser Tube
Safety Guard Class I (FDA Certified)
Work Table Area 20.08" (510mm)*11.47" (290mm)
Max. Workpiece Height(without honeycomb tray) 2" (51mm)
Work Table Surface Black (Special surface finishing technique helps reduce burn marks or discoloration)
Max. Carving Speed 1200mm/s
Carving Precision 0.001” (0.01mm)
Noise Rating ≤70dB
Rotary Engraving diameter 30mm-74mm
Rotary Engraving Length ≤245mm
Control Software Gweikecloud Web Based,Gweikecloud Offline, Lightburn
Connection / Transmission Wi-Fi, USB, Ethernet
Supported File Type SVG, DXF, JPG, JPEG, PNG, BMP, TIF, CR2, etc.
Design Software AutoCAD, Solidworks, Inkscape, CorelDRAW, PowerPoint, Illustrator, Photoshop, Google AutoDraw, etc.
Power AC 110-220V±10%,50-60Hz
Gross Power 550W
Nonoperating Temperature 0~45°C
Relative Humidity 5~90°C
Operating Ambient Temperature 0~35°C
Machine Dimensions 38.2"*22.2"*9.2" (970mm*565mm*234.5mm)
Total Weight 58kg
Cameras: 5 MP ultra-wide-angle camera wide angle & macro
Built-in air pump
Dual high-efficiency internal LED strips
|gweike cloud RF||Glowforge|
|Working Area||510mm*290mm||495mm x 279mm|
|Software||Lightburn, Offline software, gweike cloud Web base||Glowforge Web base|
|Laser Power||38W||40W(Basic/Plus), 45W (Pro)|
|Emergency Stop Switch||Yes||No|
|USB Port Support||Yes||No|
|Inline Duct fan||Yes||No|
|After-sale Support||7*24 online service||Appointment only, by email|
|Warranty Time||12 month||12 months, 6 months(Basic)|
|Mother of Pearl||✓||✓|
Everything was as described on Sexy Cyborg youtube.
The benefit of the RF tube is no water to deal with and worry about freezing (I am in Maryland) but, cutting is more limited. Weight the pro's & cons of each for your use.
The only thing that would be nice a galv bed so you can use magnets to hold down material. The bed that shipped with the unit is Alum.
Have not used the Gweike Cloud since the location of the machine does not have internet.
Works great with Light Burn.
