Package List
![](http://shop.gweikecloud.com/cdn/shop/files/e8ea3da030ba0d62024bd7731ae87052.jpg?v=1703496876&width=1400)
![](http://shop.gweikecloud.com/cdn/shop/files/a403573c53f4f3a2d6feaea01a1ef6ab.jpg?v=1703496905&width=750)
![](http://shop.gweikecloud.com/cdn/shop/files/10_{width}x.png?v=1699597181)
Raycus Q-Switched Pulse Fiber Laser
-Highly stable laser output & single-pulse energy
-Exceptional peak power, optional spot diameter
-Higher marking efficiency & reliability
Support Lightburn (EZCAD Control)
-Rotating engraving
-Multi galvanometer compatibility
-Support auto focus
![](http://shop.gweikecloud.com/cdn/shop/files/14_{width}x.png?v=1699597303)
![](http://shop.gweikecloud.com/cdn/shop/files/05_6d42a491-5344-4e2f-9664-04d5da58e750.jpg?v=1699923685&width=750)
![](http://shop.gweikecloud.com/cdn/shop/files/18_4c37abdc-6596-473c-a387-df60945c2a61_{width}x.png?v=1699597437)
Sino Galvo Galvanometer
-High speed galvanometer scanning
-Adopting SCANLAB technology, digital signal
-Higher precision and speed
Specs Summary
Laser Power | 30W/50W/70W/100W |
Laser Wavelength | 1064nm |
Q-frequency | 1-4000khz |
PMW | 0-20, Adjustable |
Divergence | 0.3mard |
Marking Range | 110*110mm/150*150mm/175*175mm/220*220mm/250*250mm/300*300mm |
Minimum Character | O.1mm |
Minimum Line Width | 0.01mm |
Minimum Depth | 0-1mm(Depending on the materials) |
Engraving Line Speed | ≤7000mm/s |
Repeatability Accuracy | ±0.001mm |
Beam Quality | M2:1.2-1.8 |
Operating System | Windows, MacOS, and Linux |
Graphic Format Supported | BMP,JPG,GIF,PNG,TIF,AI,DXF,DST,PLT,etc. |
Working Voltage | 110-220V/50Hz |
Unit Power | <0.5kw |
Working Environment Required | Clean and dust free or dust less |
Laser Module Lifespan | >100000 hrs |
Laser Source | Raycus Q-S |
Laser head | Sino-galvo |
F-thete Lens | wavelength |
Control | EZCAD2 |
